DERAY KYF-190

Thin Wall Heat Shrink Tubing

The DERAY KYF-190 is a thin-wall, high-temperature heat shrink tubing made from PVDF (Kynar®), engineered for applications requiring exceptional heat resistance, chemical protection, and mechanical durability. With a continuous operating temperature up to 190 °C, this tubing is ideal for aerospace, automotive, and industrial assemblies exposed to extreme environments.

Standards

  • VW 60360-3
  • UL 224 125°C VW-1
  • QPL SAE AS23053/18
  • Class 2
  • Is CNES approved
  • Listed in the Matrex database
DERAY KYF-190

Key Features & Benefits

  • High-Temperature Performance: Continuous use from -55 °C to +190 °C.
  • Superior Chemical Resistance: Withstands fuels, oils, solvents, and cleaning agents.
  • Flame Retardant & Semi-Rigid: Provides excellent protection while maintaining form stability.
  • 2:1 Shrink Ratio: Ensures a snug fit over wires and components for reliable insulation.
  • Exceptional Clarity: Transparent finish allows easy inspection of covered parts or labels.
  • Mechanical Protection: Offers strong resistance to abrasion and cut-through damage.

Material & Options

  • Material: PVDF (Kynar®)
  • Shrink Ratio: 2:1
  • Operating Range: -55 °C to +190 °C
  • Color: Clear (standard), black optional
  • Packaging: Spools, reels, or pre-cut lengths
  • Meets flame-retardant and environmental compliance standards

Why Choose DERAY KYF-190?

The DERAY KYF-190 delivers outstanding performance where heat, chemicals, and mechanical stress converge. Its thin-wall PVDF construction ensures longevity, while its clarity and flame-retardant design make it a trusted choice for high-specification electrical insulation and component protection

Ordering & Availability

  • Multiple sizes and diameters available
  • Supplied in standard reels or custom lengths
  • Technical datasheets and compliance documentation available upon request

Need superior protection and visibility for your high-temperature wiring?

Contact Do-X Logistics today to request a quote for DERAY KYF-190 Thin Wall Heat Shrink Tubing, built for precision and endurance in demanding environments.

Interested in our products?

Leave your details, and we'll get back to you:

Download Datasheet

Flexible Thin Wall Kynar® (-55°C to 190°C, 2:1 Shrink)

# P/N Product description Package FT/Spool Manufacturer
1 I-DERAY®-KYF190-TR-3/64 DERAY®-KYF 190 – 3/64″-TR 984 DSG-Canusa
2 I-DERAY®-KYF190-TR-1/16 DERAY®-KYF 190 – 1/16″-TR 984 DSG-Canusa
3 I-DERAY®-KYF190-TR-3/32 DERAY®-KYF 190 – 3/32″-TR 984 DSG-Canusa
4 I-DERAY®-KYF190-TR-1/8 DERAY®-KYF 190 – 1/8″-TR 984 DSG-Canusa
5 I-DERAY®-KYF190-TR-3/16 DERAY®-KYF 190 – 3/16″-TR 984 DSG-Canusa
6 I-DERAY®-KYF190-TR-1/4 DERAY®-KYF 190 – 1/4″-TR 984 DSG-Canusa
7 I-DERAY®-KYF190-TR-3/8 DERAY®-KYF 190 – 3/8″-TR 492 DSG-Canusa
8 I-DERAY®-KYF190-TR-1/2 DERAY®-KYF 190 – 1/2″-TR 328 DSG-Canusa
