DERAY KY-175

Thin Wall Heat Shrink Tubing

The DERAY KY-175 is a semi-rigid, thin-wall, clear heat shrink tubing made from PVDF (Kynar®). It’s built for challenging applications needing visibility, chemical resistance, and mechanical protection. Its transparency makes it ideal where inspection of underlying wires or components is required, while its properties ensure durability in harsh environments.

Standards

  • UL 224 125°C VW-1
  • CSA 22.2 No 198.1 125°C
  • DEF STAN 59-97 Type 3
  • BS G198 Part 4 Type 20
  • VG 95343 Part 5 Type F
  • QPL SAE AS23053/8
  • Is CNES approved
  • Listed in the Matrex database
DERAY KY-175

Key Features & Benefits

  • Shrink Ratio 2:1– accommodates varying wire diameters while ensuring a tight fit
  • Temperature Range: -55 °C to +175 °C continuous operation
  • Flame Retardant & Semi-Rigid: Excellent fire performance while maintaining shape stability
  • Chemical & Solvent Resistance: Withstands aggressive fluids, oils, and harsh chemicals
  • Abrasion & Cut-through Resistance: Good mechanical protection in demanding environments
  • Transparent/See-Through: Allows visual inspection of wire and printed labels beneath

Material & Options

  • Material: PVDF (Kynar®), thin-wall construction
  • Color: Clear (standard), black versions available
  • Shrink temperature: minimum 175 °C
  • Available internal diameters and wall thicknesses in several sizes
  • Supplied in spools or custom cut lengths

Why Choose DERAY KY-175?

DERAY KY-175 combines high-temperature endurance, chemical robustness, and visual clarity, making it a top-tier choice for critical wiring applications. Its blend of flexibility and protection is ideal in systems where reliability under stress is non-negotiable.

Ordering & Availability

  • Offered in standard and custom sizes
  • Cut lengths or full spools
  • Technical datasheets, performance data, and quality certifications are available

Need a durable, high-performance heat shrink for your specialty wiring?

Contact Do-X Logistics today to request a quote for DERAY KY-175 Thin Wall Heat Shrink Tubing tailored to your project’s temperature, mechanical, and visibility requirements.

Interested in our products?

Leave your details, and we'll get back to you:

Download Datasheet

Semi-rigid Thin Wall Kynar® (-55°C to 175°C, 2:1 Shrink)

# P/N Product description Package FT/Spool DSG-Canusa
1 I-DERAY®-KYF175-TR-3/64 DERAY®-KY 175 – 3/64″-TR 984 DSG-Canusa
2 I-DERAY®-KYF175-TR-1/16 DERAY®-KY 175 – 1/16″-TR 984 DSG-Canusa
3 I-DERAY®-KYF175-TR-3/32 DERAY®-KY 175 – 3/32″-TR 984 DSG-Canusa
4 I-DERAY®-KYF175-TR-1/8 DERAY®-KY 175 – 1/8″-TR 984 DSG-Canusa
5 I-DERAY®-KYF175-TR-3/16 DERAY®-KY 175 – 3/16″-TR 984 DSG-Canusa
6 I-DERAY®-KYF175-TR-1/4 DERAY®-KY 175 – 1/4″-TR 984 DSG-Canusa
7 I-DERAY®-KYF175-TR-3/8 DERAY®-KY 175 – 3/8″-TR 492 DSG-Canusa
8 I-DERAY®-KYF175-TR-1/2 DERAY®-KY 175 – 1/2″-TR 328 DSG-Canusa
9 I-DERAY®-KYF175-TR-3/4 DERAY®-KY 175 – 3/4″-TR 164 DSG-Canusa
10 I-DERAY®-KYF175-TR-1 DERAY®-KY 175 – 1″-TR 164 DSG-Canusa
