LS-V200

Heat Shrink Tubing

The LS-V200 is a high-performance fluoroelastomer (Viton®-based) heat-shrink tubing designed for extreme environments that demand superior heat, chemical, and oil resistance. With a 2:1 shrink ratio and continuous operation up to 200 °C, it delivers long-lasting protection for aerospace, industrial, and military wiring applications.

Standards

  • MIL-DTL-23053/13 standard
  • QPL approved
LS-V200

Key Features & Benefits

  • 2:1 shrink ratio for a secure, uniform fit over cables and connectors.
  • Exceptional temperature range from -55 °C to +200 °C for high-heat applications.
  • Outstanding chemical and oil resistance, ideal for harsh environments.
  • Flame-retardant and specification-grade, compliant with SAE AS23053/13 standards.
  • Durable mechanical protection against abrasion, vibration, and fluid exposure.

Material & Options

  • Material: Fluoroelastomer (Viton®-based).
  • Shrink Ratio: 2:1.
  • Temperature Range: -55 °C to +200 °C.
  • Standards Compliance: Meets SAE AS23053/13 (MIL-DTL-23053/13).
  • Color: Standard black (other colors available upon request).
  • Packaging: Available in reels, spools, or cut lengths.

Why Choose LS-V200?

When your application requires maximum heat tolerance, chemical resistance, and durability, the LS-V200 provides the professional-grade protection you can rely on. It’s the go-to choice for engineers and manufacturers who demand performance without compromise.

Ordering & Availability

  • Available in multiple diameters and lengths.
  • Supplied in reels or pre-cut sections for convenience.
  • Technical datasheets and certifications available upon request.
  • Ideal for OEM production, retrofits, and field installations.

Protect your wiring systems with LS-V200 Heat Shrink Tubing

The ultimate solution for high-temperature and chemical-resistant insulation.
Contact Do-X Logistics today to request a quote or custom specifications.

Interested in our products?

Leave your details, and we'll get back to you:

Download Datasheet

Do-X P/N

STANDARD SIZE (Inch)

EXPANDED INSIDE Ø (mm)

RECOVERED MAX INSIDE Ø (mm)

RECOVERED MIN. THICKNESS AT ANY POINT (mm)

STANDARD LENGTH (m)

I-M23053/18-001

1/8

3.7 ± 0.3

1.6

0.65

200

I-M23053/18-002

3/16

5.0 ± 0.3

2.4

0.72

100

I-M23053/18-003

1/4

6.9 ± 0.5

3.2

0.72

100

I-M23053/18-004

3/8

10.0 ± 0.5

4.7

0.72

50

I-M23053/18-005

1/2

13.2 ± 0.5

6.4

0.72

50

I-M23053/18-006

5/8

16.9 ± 1.0

7.9

0.90

50

I-M23053/18-007

3/4

20.1 ± 1.0

9.5

0.90

50

I-M23053/18-008

7/8

23.2 ± 1.0

11.1

0.92

50

I-M23053/18-009

1

27.4 ± 2.0

12.7

0.92

50

I-M23053/18-010

1-1/4

34.0 ± 2.0

15.9

1.02

31

I-M23053/18-011

1.5

41.0 ± 2.0

19.1

1.02

31
